Mechanical

Dimensions

• 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2 in.)

Weight

• 4.7 kg (10.4 lb.)

Enclosure material

• Aluminium CNC, SGCC steel

Mount material

• SGCC steel

Hardware

Processor

• Quad-core ARM Cortex-A57 at 2.0 GHz

System memory

• 8 GB DDR4

On-board storage

• 32 GB eMMC
• Integrated 128 GB SSD

Management interface

• Ethernet
• Bluetooth

Networking interface

• LAN:
  • 8 x GbE RJ45 ports
  • 1 x 10G SFP+ port
• WAN:
  • 1 x 2.5 GbE RJ45 port
  • 1 x 10G SFP+ port

IDS/IPS throughput

• 5 Gbps
  • Note: Measured with iPerf3.

Power method

• 1 x Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
• 1 x USP-RPS DC input, 12V DC, 4.6A (sold separately)

Power supply

• AC/DC, internal, 100W

Supported voltage range

• 100—240V AC

Max. power consumption

• 60W

ESD/EMP protection

• Air: ± 15kV, contact: ± 8kV

LCM display

• 1 x 1.3-inch touchscreen

Button

• Factory reset

Ambient operating temperature

• -10°C to 40°C (14°F to 104°F)

Ambient operating humidity

• 5% to 95% noncondensing

Certifications

• CE, FCC, IC

Gateway Features

Performance

• Redundant WAN with failover and load balancing
• WiFi QoS with UniFi APs
• Application, domain, and country-based QoS
• Application and device type identification
• Additional internet failover with LTE Backup
• Internet quality and outage reporting

Next-generation security

• Application-aware firewall rules
• Signature-based IPS/IDS threat detection
• Content, country, domain, and ad filtering
• VLAN/subnet-based traffic segmentation
• Full stateful firewall

Advanced networking

• Licence-free SD-WAN
• WireGuard, L2TP and OpenVPN server
• OpenVPN client
• OpenVPN and IPsec site-to-site VPN
• One-click Teleport and Identity VPN
• Policy-based WAN and VPN routing
• DHCP relay
• Customisable DHCP server
• IGMP proxy
• IPv6 ISP support

LEDs

Ethernet

• Green: link/activity

SFP+

• Green: link/activity

HDD

• White: disk activity
• Amber: disk error

RPS

• Blue: ready

Standard Warranty: 1-Years
