Ubiquiti U7-Pro-Max UniFi Tri-Band WiFi 7 Access Point
Ubiquiti U7-Pro-Max UniFi Tri-Band WiFi 7 Access Point is a ceiling-mounted AP with eight (8) spatial streams, 6 GHz support, and a dedicated spectral scanning engine for interference-free WiFi in demanding, large-scale environments.
Please note:Â This Ubiquiti U7-Pro-Max is not supplied with a PoE injector. This product is not yet officially WiFi 7 certified and may not support all the mandatory features as ratified in the IEEE 802.11be specification.
£257.63 inc.VAT / £214.69 exc.VAT
Ubiquiti U7-Pro-Max UniFi Tri-Band WiFi 7 Access Point (15.1Gbps BE)
Ubiquiti U7-Pro-Max UniFi Tri-Band WiFi 7 Access Point
The Ubiquiti U7-Pro-Max UniFi Tri-Band WiFi 7 Access Point with eight (8) spatial streams, 6 GHz support, and a dedicated spectral scanning engine for interference-free WiFi in demanding, large-scale environments. The Ubiquiti U7-PRO-MAX represents an advancement on its counterpart, the U7-PRO, offering 8 spatial streams instead of 6, a greater area of coverage, and support for 500+ devices instead of 300+. Throughput is also improved, with this access point offering a total aggregate data throughput rate of 15.1 Gbps. The U7-PRO-MAX also supports the relatively uncongested 6 GHz band, and supports 2×2 MIMO on the 2.4 and 6 GHz bands and 4×4 MIMO on the 5 GHz.
The U7-PRO-MAX has also introduced real-time spectral analysis through UniFi Network 8.2.93 and higher, offering enhanced channel selection and real-time network reporting. Other software features include 802.1Q VLAN support, advanced QoS and guest traffic isolation. This access point offers both wall and ceiling mounting options, and can be powered by 802.11at PoE+ through its 2.5GbE RJ45 port.
Key Features
- WiFi 7 with 6 GHz support.
- Eight (8) spatial streams.
- Real-time spectral analysis for enhanced channel selection (requires UniFi Network 8.2.93 and later).
- 160 m² (1,750 ft²) coverage.
- Supports 500+ connected devices.
- Powered using PoE+.
- 2.5 GbE uplink port.
- Multi-Link Operation (MLO) capability (coming soon).
Specifications
Mechanical Specifications
Dimensions
- 206 x 46 mm (8.1 x 1.8 in.)
Weight
- 680 g (1.5 lb)
Enclosure material
- Polycarbonate, aluminium
Mount material
- Stainless steel (SUS304), galvanised steel (SGCC)
Hardware Specifications
Networking interface
- 1 x 1/2.5 GbE RJ45 port
Management interface
- Ethernet
Power method
- PoE+
Power supply
- UniFi PoE switch
Supported voltage range
- 44—57V DC
Max. power consumption
- 22W
Max. TX power
- 2.4 GHz: 23 dBm
- 5 GHz: 29 dBm
- 6 GHz: 23 dBm
MIMO
- 2.4 GHz: 2 x 2
- 5 GHz: 4 x 4
- 6 GHz: 2 x 2
Throughput rate
- 2.4 GHz: 688 Mbps
- 5 GHz: 8648 Mbps
- 6 GHz: 5765 Mbps
Antenna gain
- 2.4 GHz: 4 dBi
- 5 GHz: 6 dBi
- 6 GHz: 5.9 dBi
LEDs
- White/blue
Button
- Factory reset
Mounting
- Wall, ceiling (Included)
Ambient operating temperature
- -30°C to 60°C (-22°F to 140°F)
Ambient operating humidity
- 5 to 95% non-condensing
Certifications
- CE, FCC, IC
Software Specifications
WiFi standards
- 802.11a/b/g/n/ac/ax/be
Wireless security
- WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID
- 8 per radio
VLAN
- 802.1Q
Advanced QoS
- Per-user rate limiting
Guest traffic isolation
- Supported
Concurrent clients
- 500+
Supported Data Rates
802.11a
- 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
- 1, 2, 5.5, 11 Mbps
802.11g
- 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n
- 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
802.11ac (WiFi 5)
- 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6/6E)
- 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
802.11be (WiFi 7)
- 7.3 Mbps to 5.7 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320)
Application Requirements
UniFi Network
- Version 8.2.93 and later
Standard Warranty: 1-Years
| Weight | 0.68 kg |
|---|---|
| Dimensions | 20.6 × 4.6 cm |
